COMPLETE CIRCUIT PROTECTION: Combines a WiFi automatic reclosing accessory with a 1P+N 6kA RCBO to provide residual current, overload and short circuit protection in one coordinated set.
-
TYPE A : Type A for AC and pulsating DC residual currents generated by modern electronic appliances.
-
REMOTE ON OFF CONTROL: Connect the set to a 2.4GHz WiFi network and use the Smart Life app to remotely open or close the circuit without an additional gateway.
-
AUTOMATIC POWER RESTORATION: The motor operator performs up to three reclosing attempts at 30 second intervals after the RCBO trips, reducing unnecessary site visits caused by temporary faults.
-
COMPACT 1P+N SOLUTION: Suitable for homes, shops, farms, pumps, outdoor equipment and remote distribution panels requiring leakage, overload and short circuit protection together with smart operation.
| Item | TOSAR-BD6 |
| Product Type | Wi-Fi Auto Recloser RCBO |
| Standard | IEC/EN 61009-1 |
| Leakage Type | Type a |
| Leakage current value | 10mA, 30mA |
| Rated Voltage | 2p:230V~ 4p:400V~ |
| Rated Current | 10A, 16A, 20A, 25A, 32A, 40A, 63A |
| Reclosing Time Interval | 30s-30s-30s |
| Reclosing Cycle | 3 |
| Electrical Life | 10000 |
| Communication Protocol | 2.4GhZ Wi-Fi |
| APP | TUYA SMART LIFE |
| Smart Function | Remote Control |
| Manufacturer | Changyou Technology |
| Brand | Chayo |
